Weight（kg）

Gross Weight

11500

Overall Size(mm)

10400×2470×3900

Curb Weight

11305

Axial Distance(mm)

5000

Motor

Model

YC4EG170-50

Emission Standard

Diesel V

Power/Displacement(KW/ml)

125/4730

Chassis Factory

Guangxi yuchai machinery Co.

Capacity

Max Driving Speed(km/h)

100

Wheel Distance(mm)

Front Axle

1858

Driving Cab Passengers(man)

3

Rear Axle

1806

No.of Axles

2

Suspension(mm)

Front suspension

1230

Axles Load(Kg)

4605/7695

Rear Suspension

3090

Number of Tyre

6

Driving angle(°)

Approach angle

19

Tyre Spec.

9.00R20/9.00-20

Departure angle

10

Function

Max Work Height

22m

Easy to operate

With ignition

Rated Load of Platform

200kg

Swing angle

Two-way 360° continuous rotation

Rotating Speed

1~2r/min

Rated Lifting Weight

1000kg

Max Lifting Height

12.5m

Electronic control operation

Up and down double operation
