Weight（kg）

Gross Weight

7490

Overall Size(mm)

8400×2310×3510

Curb Weight

7295

Axial Distance(mm)

3800

Motor

Model

CY4SK251

Emission Standard

Diesel V

Power/Displacement(KW/ml)

115/3856/156

Chassis Factory

Dongfeng Motor Co.,Ltd

Capacity

Max Driving Speed(km/h)

99

Wheel Distance(mm)

Front Axle

1740

Driving Cab Passengers(man)

3

Rear Axle

1610

No.of Axles

2

Suspension(mm)

Front suspension

1130

Axles Load(Kg)

3000/4490

Rear Suspension

2280

Number of Tyre

6

Driving angle(°)

Approach angle

20

Tyre Spec.

7.50R16

Departure angle

14

Function

Max Work Height

18m

Easy to operate

With ignition

Rated Load of Platform

200kg

Swing angle

Two-way 360° continuous rotation

Rotating Speed

1~2r/min

Rated Lifting Weight

1000kg

Max Lifting Height

8.3m

Electronic control operation

Up and down double operation
