Weight（kg）

Gross Weight

10300

Overall Size(mm)

9380x2470x3800

Curb Weight

10105

Axial Distance(mm)

4700

Motor

Model

YC4S170-50

Emission Standard

Diesel V

Power/Displacement(KW/ml)

125/3767

Chassis Factory

Guangxi yuchai machinery Co., Ltd

Capacity

Max Driving Speed(km/h)

110

Wheel Distance(mm)

Front Axle

1858

Driving Cab Passengers(man)

3

Rear Axle

1806

No.of Axles

2

Suspension(mm)

Front suspension

1230

Axles Load(Kg)

4120/6180

Rear Suspension

2500

Number of Tyre

6

Driving angle(°)

Approach angle

18

Tyre Spec.

8.25R20

Departure angle

12.8

Function

Max Work Height

20m

Easy to operate

With ignition

Rated Load of Platform

200kg

Swing angle

Two-way 360° continuous rotation

Rotating Speed

1~2r/min

Rated Lifting Weight

1000kg

Max Lifting Height

11.5m

Electronic control operation

Up and down double operation
